IMG-Stage Line ULM-164 6 Kanäle Zeilensplitter

    ULM-164

          Neu

          ULM-164 /SW
          Nummer: 20.2240
          Universal Line Mixer, 6 Kanäle < /p>

          Mehr Infos

          Sammeln Sie mit dem Kauf dieses Artikels bis zu 13 Treuepunkte. Ihr Warenkorb hat insgesamt 13 Treuepunkte die umgewandelt werden können in einen Gutschein im Wert von € 2,60.


                € 268,59

                Rabatt auf Ihre Bestellung Rabatt auf Ihre Bestellung
                Kostenloser Versand Kostenloser Versand in NL
                Volumenrabatt Volumenrabatt
                Bonus-System Bonus-System
                Sichere Zahlung Sichere Zahlung
                Geld-zurück-Garantie Geld-zurück-Garantie
                Trustpilot Trustpilot

        Mengenrabatt

          Menge Rabatt Sie sparen
          2 2% Bis zu € 10,74
          4 4% Bis zu € 42,97
          6 6% Bis zu € 96,69
          8 8% Bis zu € 171,90
          10 10% Bis zu € 268,59

        Mehr Infos IMG-Stage Line ULM-164 6 Kanäle Zeilensplitter

        IMG-Stage Line ULM -164 6-way line splitter, with 2 separate outputs RCA and 6.3 mm jack



        Product Discription:
        • Universal line mixer, 6 channels.
        • 6 stereo inputs/mono inputs
        • 2 stereo outputs, independent of each other (master 1 via RCA and 6.3 mm jack), 1 mono output
        • 3-way equalizer
        • LED VU meter, switchable for both outputs
        • Clip LED for each channel
        • Balance controls with centre click for the stereo input channels
        • Extended muting function
        • Adjustable headphone output
        • 482 mm (19") rack installation, 1 RS

        Technical Facts:
        • Line input, stereo 150 mV/50 kΩ

        • Line input, mono 150 mV/25 kΩ

        • Master output, stereo 1 V/600 Ω

        • Master output, mono 2 V/600 Ω

        • Headphones, stereo ≥ 8 Ω

        • Frequency range 20-20,000 Hz

        • THD 0.05 %

        • S/N ratio 69 dB, unweighted

        • Equalizer, bass ±12 dB/80 Hz

        • Equalizer, midrange ±12 dB/1 kHz

        • Equalizer, treble ±12 dB/10 kHz

        • Power supply 230 V/50 Hz/10 VA

        • Admiss. ambient temp. 0-40 °C

        • Dimensions 482x48x175 mm, 1 RS

        • Weight 2.3 kg

        • Line input, stereo 6 x RCA L/R

        • Line input, mono 6 x 6.3 mm jack, unbal.

        • Master output, stereo 2 x RCA (1 x 6.3 mm) L/R

        • Master output, mono 1 x 6.3 mm jack

        • Headphones 1 x 6.3 mm jack
