PCI MAX 3000 FM Zender (3W) View larger

PCI MAX 3000 FM Transmitter (3W)

PCI3w

New

PCI MAX 3000 is a computer card that will change the way you listen to your MP3's or other audio via PC. It will effectively change your PC into a stereo FM radio station, it is a small digital FM transmitter in a form of a PCI PC card.

More details


✓ Good price ✓ Safe to Pay
✓ Free shipping to NL ✓ Money back guarantee
✓ Volume discount ✓ Bonus system
✓ Large assortment ✓ QShops certification

By buying this product you can collect up to 9 loyalty points. Your cart will total 9 loyalty points that can be converted into a voucher of EUR 1,80.


EUR 194,99 tax incl.

Add to wishlist

Volume discounts

Quantity Price You Save
5 EUR 187,19 Up to EUR 39,00
10 EUR 177,44 Up to EUR 175,49

Accessories

More info



 PCI MAX 3000 PC stereo FM-transmitter card




Product Discription:
DIGITAL RDS STEREO FM TRANSMITTER for your PC

What is PCI MAX 3000?
PCI MAX 3000 is a computer card that will change the way you listen to your MP3's or other audio via PC. It will effectively change your PC into a stereo FM radio station, it is a small digital FM transmitter in a form of a PCI PC card. You will be able to play your audio files (CD, wav, MP3, real audio etc.) from your PC through radio waves directly to your household radio receiver in the next room, in the living room, across your yard, in whole block of flats....or for the entire village/small city. You need just an ordinary radio receiver to receive your signal. The included software (also available in the support section of this website) lets you set the frequency and the output power. You can either service
your living room, garden or anentire community. Get rid of those pesky cables!

PCI MAX was featured in the Playboy magazine.

What is new since PCI MAX 2007?
  • PCIMAX3000+ is a major re-design of PCIMAX3000+
  • PCIMAX3000+ comes with the new QSonic VCO/PLL system, giving perfect audio response flatness and good bass response
  • PCIMAX3000+ features built-in PC sound card. This allows direct digital audio playback for low noise high quality transmission.
  •  It is still possible to drive audio from analog source as well (3.5" phono).
  • Microphone input
  • Stronger and much more robust RF output stage for more RF power (3W is possible).
  • RF output stage protection.
  • Much better output LPF filter (7-element elliptical).
  • RDS daughter board from model 2007+ still compatible.
  • Number of small improvements for better sound, stereo separation and increased reliability.
  • External power supply no longer required for full output power.
  • PCIMAX3000+ can be used outside of the PC, simply connect to PC via USB cable. External mains power supply is used in this configuration.
  • And yes, we have a new driver



Technical Facts:
  • Frequency band: 87.5 (86) -108MHz FM BAND, 50KHz steps (76-108 possible for Japan)
  • Stereo mode with excellent stereo separation
  • Stereo 3.5 phono socket audio input
  • USB interface
  • RDS functionality with optional RDS daughter board
  • When used inside PC accepts DC power from 3.5" harddisk power plug
  • Frequency, mode and RF output power adjustment with a click of a mouse (Windows) or with LCD module
  • RF output power: up to about 4W (3W model), depending on the model
  • Consider one of the better antennas from our website or any of the ones listed under accesories (do check those out).
NOTE: You need external 12-15V stabilized power supply to obtain full output power. All versions starting with 1000mW and up require a good antenna in order to prevent damage to output stage. Consider one of the better antennas from our website or any of the ones listed under accesories (do check those out).


Difference between models of PCI MAX 2007+:
The only difference between different models is output power. Cards typically output up to and over 3000mW. Operation at highest power level requires a case fan blowing onto the output transistor heatsink (from the side) Failure to use such a fan prevents the unit to reach full power as the temp. protection starts to reduce the power. Such a fan is recommended for all versions starting at 1W and going up.
