100W FM Transmitter SOLID STATE EM 100 DIG PLUS OMB

    100W FM ZENDER SOLID STATE EM 100 DIG PLUS OMB View larger

    100W FM Transmitter SOLID STATE EM 100 DIG PLUS OMB

    EM100 DIG P

    The EM 100 DIG PLUS is a 100W FM transmitter made up with the most modern available technology so as to provide the maximum performance at minimal cost, while fully meeting the technical regulations. Flexibility, quality, compactness, and low electrical consumption make the EM 100 DIG PLUS one of the best offered on the market today. This transmitter can be supplied with an internal digital stereo generator board (60dB separation).

    By buying this product you can collect up to 121 loyalty points. Your cart will total 121 loyalty points that can be converted into a voucher of € 24,20.


    € 2.434,99

    Discount on your Order Discount on your Order
    Free Shipping Free Shipping in NL
    Volume Discount Volume Discount
    Bonus System Bonus System
    Secure Payment Secure Payment
    Money Back Guarantee Money Back Guarantee
    Trustpilot Trustpilot

    Volume discounts

    Quantity Discount You Save
    2 2% Up to € 97,40
    4 4% Up to € 389,60
    6 6% Up to € 876,60
    8 8% Up to € 1.558,39
    10 10% Up to € 2.434,99

    Product information 100W FM Transmitter SOLID STATE EM 100 DIG PLUS OMB

    Product Discription:

    MAIN ADVANTAGES OF THE EM 100 DIG PLUS FM TRANSMITTER MANUFACTURED BY OMB:

    • Super-compact size and reduced weight.
    • Low performance costs.
    • Robust modular construction.
    • Easy to use and to configure. The transceiver uses a control interface, which is equipped with a large LCD screen, a multifunction knob, and few buttons.
    • Nominal RF output power over the full FM range particularly stable against time.
    • Power section entirely modular and highly reliable.
    • RF output stage with reverse intermodulation figure lower than the standard bipolar construction.
    • Low level of dissipation.
    • Stable, reliable power supply.
    • Easy diagnosis and easy-to-read parameters.
    • Compliance with the strictest regulations.







    Technical specifications:






    RANGE 87.5-108MHz
    FM MODULATION 75KHz (adjustable) peak deviation. Mono 180kF3E and Stereo 256kF3E
    AUDIO/MPX INPUT LEVEL -3.5 to +12.5dBm @ 75KHz deviation
    AUDIO INPUT CONNECTORS XLR(F)
    AES/EBU DIGITAL INPUT CONNECTOR (OPTIONAL) XLR(F), 110Ω balanced
    SEPARATION BETWEEN CHANNELS (OPTIONAL STEREO GENERATOR) 60dB
    AUX. CHANNEL INPUT LEVEL (RDS/SCA) 7.5KHz deviation: -12.5 to 3.5dBm

    2KHz deviation: -24 to -8dBm

    AUX. CHANNEL INPUT IMPEDANCE 10KOhm
    MODULATION DISTORTION 7.5KHz deviation: <0.05%, 0.02% typical

    2KHz deviation: <0.2%, 0.05% typical

    MONO S/N RATIO 30 to 20000Hz: >76dB, 86dB typical

    CCIR: >75dB, 81dB typical

    STEREO S/N RATIO 30 to 20000Hz: >72dB, 77dB typical

    CCIR: >68dB, 72dB typical

    AUDIO CHANNELS BANDWIDTH 30 to 15000Hz ±0.1dB
    PRE-EMPHASIS TIME CONSTANT Selectable, 25/50/75 microseconds
    NOMINAL RF OUTPUT POWER 100W
    TRANSMITTER TUNING STEPS 10/100KHz
    OUTPUT POWER ALC STABILITY ±3%
    HARMONICS AND SPURIOUS EMISSIONS <80dBc
    RF OUTPUT IMPEDANCE 50Ω
    RF OUTPUT CONNECTOR N type
    RF SAMPLER CONNECTOR BNC type
    POWER SUPPLY Single phase 110-230Vac ±15% 50/60Hz
    OPERATING TEMPERATURE RANGE 0 to 40°C recommended, -10 to +55° max.
    RELATIVE HUMIDITY Up to 95% not condensed
