100W FM ZENDER SOLID STATE EM 100 DIG PLUS OMB

EM100 DIG P

        Nieuw

            The EM 100 DIG PLUS is a 100W FM transmitter made up with the most modern available technology so as to provide the maximum performance at minimal cost, while fully meeting the technical regulations. Flexibility, quality, compactness, and low electrical consumption make the EM 100 DIG PLUS one of the best offered on the market today. This transmitter can be supplied with an internal digital stereo generator board (60dB separation).

          Meer details

        Bij het kopen van dit product krijgt u in totaal 108 Loyaliteit punten. Uw winkelwagen bevat een totaal aan 108 Loyaliteit punten die omgezet kunnen worden in een waardebon van € 21,60.


              € 2.165,28

              Korting op je bestelling Korting op je bestelling
              Gratis verzenden Gratis verzenden tot 10 KG
              Volume korting Volume korting
              Bonus systeem Bonus systeem
              Veilig betalen Veilig betalen
              Niet goed geld terug Niet goed geld terug
              QShops certificaat QShops certificaat
              Trustpilot Trustpilot

      Volumekorting - 100W FM ZENDER SOLID STATE EM 100 DIG PLUS OMB

        Aantal Korting U bespaart
        2 2% Tot € 86,61
        4 4% Tot € 346,44
        6 6% Tot € 779,50
        8 8% Tot € 1.385,78
        10 10% Tot € 2.165,28

      Meer informatie

        Product Discription:

        MAIN ADVANTAGES OF THE EM 100 DIG PLUS FM TRANSMITTER MANUFACTURED BY OMB:

        • Super-compact size and reduced weight.
        • Low performance costs.
        • Robust modular construction.
        • Easy to use and to configure. The transceiver uses a control interface, which is equipped with a large LCD screen, a multifunction knob, and few buttons.
        • Nominal RF output power over the full FM range particularly stable against time.
        • Power section entirely modular and highly reliable.
        • RF output stage with reverse intermodulation figure lower than the standard bipolar construction.
        • Low level of dissipation.
        • Stable, reliable power supply.
        • Easy diagnosis and easy-to-read parameters.
        • Compliance with the strictest regulations.







        Technical specifications:






        RANGE 87.5-108MHz
        FM MODULATION 75KHz (adjustable) peak deviation. Mono 180kF3E and Stereo 256kF3E
        AUDIO/MPX INPUT LEVEL -3.5 to +12.5dBm @ 75KHz deviation
        AUDIO INPUT CONNECTORS XLR(F)
        AES/EBU DIGITAL INPUT CONNECTOR (OPTIONAL) XLR(F), 110Ω balanced
        SEPARATION BETWEEN CHANNELS (OPTIONAL STEREO GENERATOR) 60dB
        AUX. CHANNEL INPUT LEVEL (RDS/SCA) 7.5KHz deviation: -12.5 to 3.5dBm

        2KHz deviation: -24 to -8dBm

        AUX. CHANNEL INPUT IMPEDANCE 10KOhm
        MODULATION DISTORTION 7.5KHz deviation: <0.05%, 0.02% typical

        2KHz deviation: <0.2%, 0.05% typical

        MONO S/N RATIO 30 to 20000Hz: >76dB, 86dB typical

        CCIR: >75dB, 81dB typical

        STEREO S/N RATIO 30 to 20000Hz: >72dB, 77dB typical

        CCIR: >68dB, 72dB typical

        AUDIO CHANNELS BANDWIDTH 30 to 15000Hz ±0.1dB
        PRE-EMPHASIS TIME CONSTANT Selectable, 25/50/75 microseconds
        NOMINAL RF OUTPUT POWER 100W
        TRANSMITTER TUNING STEPS 10/100KHz
        OUTPUT POWER ALC STABILITY ±3%
        HARMONICS AND SPURIOUS EMISSIONS <80dBc
        RF OUTPUT IMPEDANCE 50Ω
        RF OUTPUT CONNECTOR N type
        RF SAMPLER CONNECTOR BNC type
        POWER SUPPLY Single phase 110-230Vac ±15% 50/60Hz
        OPERATING TEMPERATURE RANGE 0 to 40°C recommended, -10 to +55° max.
        RELATIVE HUMIDITY Up to 95% not condensed
