CyberMax-8000+ DSP stereo-encoder, processor

Nieuw

Bekijk groter

PCS-Electronics

Model 8000-ST

Staat Nieuw

CyberMax-8000+ DSP stereo processor with LCD display excellent stereo separation with 114x oversampling

SE8000 DSP+ with built-in compressor, limiter, balanced inputs, sharp 19KHz stereo carrier notch filter, pre-emphasis, LC input filters and ESD protected inputs which all help to bring out the best sound

Meer details

Bij het kopen van dit product krijgt u in totaal 19 Loyaliteit punten. Uw winkelwagen bevat een totaal aan 19 Loyaliteit punten die omgezet kunnen worden in een waardebon van € 3,80.

Print hier uw Productpagina

€ 392,55

Aantal

	Gratis verzenden
	Volume korting
	Bonus systeem
	Veilig betalen
	Niet goed geld terug
	QShops certificaat

Volumekorting - CyberMax-8000+ DSP stereo-encoder, processor

Aantal	Korting	U bespaart
2	2%	Tot € 15,70
3	3%	Tot € 35,33
4	4%	Tot € 62,81
5	10%	Tot € 196,28
10	15%	Tot € 588,83

Productinformatie

Product discription:

CyberMax-8000+ DSP stereo encoder offers excellent stereo separation with 114x oversampling, RDS and DSP. Based on our latest SE8000 DSP+ with built-in compressor, limiter, balanced inputs, sharp 19KHz stereo carrier notch filter, pre-emphasis, LC input filters and ESD protected inputs which all help to bring out the best sound. Perfect for a demanding, but cost-conscious broadcaster. DSP filters and others all make this encoder a real bargain. This is your perfect gateway into the world of excellent stereo separation and sound!

Technical facts:

- Audio Response: 10Hz-15KHz, DSP or LC filtered (as per CCIR standards)
- DSP: 24-bit Digital Signal Processor, Analog: LC filters
- 19KHz notch filter, >-60 dB typ
- Precise pre-emphasis, 50uS, 75uS or none
- Audio Input Impedance: 10Kohm, balanced or unbalanced
- Audio Input Level: 0 dB
- Distortion: <0.1%
- S/N ratio: >90 dB
- Separation: >60 dB typ. (much more than typical radio receivers can resolve)
- Pilot Frequency: 19 KHz, 114x oversampled MPX
- Output Impedance: 75 Ohms
- Power Requirements: 12-15VDC / 200mA
- PC Board Size: 100x120mm
- Audio connectors: all RCA jacks are mounted on the board, 3-pin jumpers for XLR balanced inputs, optional MCX or solder pads for MPX output
- Power connector: solder pads
- Output level: Ueff 1-4V adjustable with trimmer
