What Is Dante?
Dante is a complete media networking solution, and the de facto standard for digital media networking. Dante distributes uncompressed, multi-channel digital media via standard Ethernet networks, with near-zero latency and perfect synchronization.
How Does it Work?
In a Dante-enabled device, the hardware takes digital audio and ‘pa...
What Is Dante?
Dante is a complete media networking solution, and the de facto standard for digital media networking. Dante distributes uncompressed, multi-channel digital media via standard Ethernet networks, with near-zero latency and perfect synchronization.
How Does it Work?
In a Dante-enabled device, the hardware takes digital audio and ‘packetizes’ it. Basically, it segments the audio and wraps it in IP (Internet Protocol) packets suitable for transmission across an Ethernet network. The packets contain timing information and source and destination network addresses, allowing them to be efficiently routed through the network to the correct destination.
When a device receives Dante audio packets, it reconstructs them back into a continuous digital audio stream, which is then played out, recorded, or digitally processed, depending on that device’s role in the audio system.
Hardware Dante devices support exceptionally low latency (on the order of microseconds, rather than milliseconds), and common low-latency applications (for example, real-time monitoring during recording) are easily supported.
Dante AVIO AES3 EBU adapter ADP-AES3-2X2For connecting analogue devices with AES3/EBU interface to a Dante® audio network Impedance: 110 Ω (bal.) S/N ratio: > 135 dB Sampling rates: 44.1/48/96 kHz, 24 bits Connections: 1 x RJ45, 1 x XLR plug, 1 x XLR inline jack
Dante analogue input adapter ADP-DAI-1XO 1 channelFor connecting analogue audio line level devices (e.g. mixer) to a Dante® audio network Adjustable signal level: +24/+4/0 dBu, 0/-10 dBV (via Dante® controller) Frequency range: 20-20,000 Hz Impedance: 20 kΩ (bal.), 10 kΩ (unbal.) Dynamic range: > 100 dB S/N ratio: > 100 dB THD: < 0.01% Sampling...
Dante analogue output adapterr ADP-DAO-0X1For connecting analogue audio line level devices (e.g. active speakers) to a Dante® audio network Adjustable signal level: +18/+4/0 dBu, 0/-10 dBV (via Dante® controller) Frequency range: 20-20,000 Hz Impedance: 150 kΩ (bal.), 75 kΩ (unbal.) Dynamic range: > 100 dB S/N ratio: > 100 dB THD: < 0.01%...
Dante AVIO USB adapter ADP-USB-2X2 2-channel recording reproductionFor connecting a computer to a Dante® audio network 2-channel recording/reproduction Sampling rate: 48 kHz Compatible with Windows, Mac OS, IOS and Android devices, no drivers required Connections: 1 x RJ45, 1 x USB Type-A
Dante™ I/O box, for converting analogue audio signals into Dante™ streams.2 x microphone/line input (XLR, bal.) 1 x aux input (3.5 mm stereo jack) 1 x Dante™ output (EtherCon/RJ45) 1 x monitor output (3.5 mm stereo jack) Gain adjustable via recessed potentiometer (0-60 dB)
Dante™ Receiver, for converting Dante™ streams into analogue audio signals.1 x Dante™ input (EtherCon/RJ45) 1 x aux input (3.5 mm stereo jack) 2 x audio output (XLR, bal.) 1 x monitor output (3.5 mm stereo jack)
Dante audio adapter ADP-DAI-2X0For connecting analogue audio line level devices (e.g. mixer) to a Dante® audio network Adjustable signal level: +24/+4/0 dBu, 0/-10 dBV (via Dante® controller) Frequency range: 20-20,000 Hz Impedance: 20 kΩ (bal.), 10 kΩ (unbal.) Dynamic range: > 100 dB S/N ratio: > 100 dB THD: < 0.01% Sampling rates: 44.1/48/96...
