25W FM ZENDER SOLID STATE EM 25 DIG PLUS OMB

25W FM ZENDER SOLID STATE EM 25 DIG PLUS OMB - FM Zenders Bekijk groter

: OMB

: EM 25 DIG P

: Nieuw

: FM Zenders

: 25W FM ZENDER SOLID STATE EM 25 DIG PLUS OMB

EM 25 DIG PLUS is a 25W FM transmitter made up with the most modern available technology so as to provide the maximum performance at minimal cost

Bij het kopen van dit product krijgt u in totaal 89 Loyaliteit punten. Uw winkelwagen bevat een totaal aan 89 Loyaliteit punten die omgezet kunnen worden in een waardebon van € 17,80.


€ 1.789,99

Aantal Korting U bespaart
2 2% Tot € 71,60
4 4% Tot € 286,40
6 6% Tot € 644,40
8 8% Tot € 1.145,59
10 10% Tot € 1.789,99

Let op: laatste item(s) op voorraad!

Productinformatie
The EM 25 DIG PLUS is a 25W FM transmitter made up with the most modern available technology so as to provide the maximum performance at minimal cost, while fully meeting the technical regulations. Flexibility, quality, compactness, and low electrical consumption make the EM 25 DIG PLUS one of the best offered on the market today. This transmitter can be supplied with an internal digital stereo generator board (60dB separation).


Product Discription:

MAIN ADVANTAGES OF THE EM 5000 HE DIG PLUS FM TRANSMITTER MANUFACTURED BY OMB:

  • Super-compact size and reduced weight.
  • Low performance costs.
  • Robust modular construction.
  • Easy to use and to configure. The transceiver uses a control interface, which is equipped with a large LCD screen, a multifunction knob, and few buttons.
  • Nominal RF output power over the full FM range particularly stable against time.
  • Power section entirely modular and highly reliable.
  • RF output stage with reverse intermodulation figure lower than the standard bipolar construction.
  • Low level of dissipation.
  • Stable, reliable power supply.
  • Easy diagnosis and easy-to-read parameters.
  • Compliance with the strictest regulations.

 Technical specifications:

FREQUENCY RANGE 87.5-108MHz
FM MODULATION 75KHz (adjustable) peak deviation. Mono 180kF3E and Stereo 256kF3E
AUDIO/MPX INPUT LEVEL -3.5 to +12.5dBm @ 75KHz deviation
AUDIO INPUT CONNECTORS XLR(F)
AES/EBU DIGITAL INPUT CONNECTOR (OPTIONAL) XLR(F), 110Ω balanced
SEPARATION BETWEEN CHANNELS (OPTIONAL STEREO GENERATOR) 60dB
AUX. CHANNEL INPUT LEVEL (RDS/SCA) 7.5KHz deviation: -12.5 to 3.5dBm

2KHz deviation: -24 to -8dBm
AUX. CHANNEL INPUT IMPEDANCE 10KOhm
MODULATION DISTORTION 7.5KHz deviation: <0.05%, 0.02% typical

2KHz deviation: <0.2%, 0.05% typical
MONO S/N RATIO 30 to 20000Hz: >76dB, 86dB typical

CCIR: >75dB, 81dB typical
STEREO S/N RATIO 30 to 20000Hz: >72dB, 77dB typical

CCIR: >68dB, 72dB typical
AUDIO CHANNELS BANDWIDTH 30 to 15000Hz ±0.1dB
PRE-EMPHASIS TIME CONSTANT Selectable, 25/50/75 microseconds
NOMINAL RF OUTPUT POWER 25W
TRANSMITTER TUNING STEPS 10/100KHz
OUTPUT POWER ALC STABILITY ±3%
HARMONICS AND SPURIOUS EMISSIONS <80dBc
RF OUTPUT IMPEDANCE 50Ω
RF OUTPUT CONNECTOR N type
RF SAMPLER CONNECTOR BNC type
POWER SUPPLY Single phase 110-230Vac ±15% 50/60Hz
OPERATING TEMPERATURE RANGE 0 to 40°C recommended, -10 to +55° max.
RELATIVE HUMIDITY Up to 95% not condensed
