Information FM Transmitter Kits
FM exciter modules and kits are the ideal solution for professional FM transmitter systems. This category includes high-quality FM exciter kits designed for integration into existing transmitters as well as for building new stereo FM transmitters using modern DSP technology.
With these FM exciter modules, a stereo DSP FM transmitter can be created quickly and efficiently. RDS integration or replacement is also easily achieved using modular components, allowing flexible system expansion and upgrades according to your broadcast requirements.
The exciter modules feature adjustable output power, ensuring correct and stable drive levels for RF power amplifiers and final amplifier stages. This guarantees clean modulation, high audio quality, and reliable signal performance, making these modules suitable for professional broadcasting and advanced technical applications.
Discover the best products - FM Transmitter Kits
-
€ 14,99FM Transmitter KitsMaxLink cable (6pin) 30cm for stereo encoder
MaxLink cable (6pin) 30cm for stereo encoder
-
€ 284,99FM Transmitter KitsMAXPRO-8015+ 15W FM transmitter - exciter plus LCD
MAXPRO-8015+ 15W FM transmitter - exciter including LCD Qsonic PLL/VCO, excellent bass response, fast lock! The new MAX PRO 8015+ FM exciters are fine-tuned, optimized and improved version of MAXPRO7015. They bring even better S/N ratio and MAXLINK II interface for easy no-soldering wiring to the new SE8000 DSP+ stereo encoder. RF Output Power: 0 to 15 Watts, LCD power adjustment range can also be limited to 0-1W, 0-2W, 0-3W, 0-4W ... 0-15W, 0-full, this is done with a jumper (exact options vary depending on model) Output connector: 15 BNC Output Impedance: 50 Ohms Frequency range: 87.5-108MHz PLL Steps: 50KHz-500KHz, adjustable Frequency stability: +/- 20Hz Spurious/Harmonic rejection: Harmonics: >50dB, Spurious: (>80dB) Power Supply 15W: 12-15V/3A or car battery Power connector: New design with plugin with 2 screw terminals or standard barrel type Quartz Locked PLL Frequency Control Ultra Stable, Ultra Clean Output No Expensive Test Equipment Required Audio performance: Less than 0.1% distortion, 20Hz-75KHz RF output ruggedness: SWR protection Polarity protection, temp protection Pre-emphasis, 50uS, 75uS or none Audio Input Impedance: 10Kohm, unbalanced Audio Input Level: 0 dB S/N ratio: >90 dB PC Board Size 15W: 100x125mm Audio connectors: 2 pins and solder pads, MAXLINK II RF monitor: solder pads
-
€ 224,99FM Transmitter KitsAudio input board (AES/EBU (RCA+XLR+USB) + 20cm flat cable
Audio input board card now with AES/EBU adds two XLR balanced inputs and two RCA connectors plus USB audio input. Special designed for the STMAX3015+ FM Transmitter board (stereo+RDS) available in 15W, 25W
-
€ 419,99FM Transmitter KitsSTMAX 9000+ FM Exciter
The STMAX 9000+ FM exciter features digital modulation, built-in stereo, and RDS with an LCD display for easy control. Available in 15W, 25W, 50W, and 75W versions, designed for 24/7 noiseless operation.
-
€ 464,99FM Transmitter KitsDDS FM Transmitters – High-Performance Digital Exciters with DSP & RDS
Upgrade your FM broadcasts with DDS FM transmitters. Experience crystal-clear sound, GPS synchronization, RDS support, and full web control. Reliable, efficient, and future-proof!
-
€ 389,99FM Transmitter KitsSTMAX3015+ exciter (stereo+RDS) availability in 15W, 25W
DDS digital signal synthesis, excellent audio, on-board stereo and RDS The new STMAX 3015+ FM exciters combine more features into a small board than ever before. With DDS digital modulator, on-board stereo and RDS and all of this full controllable via LCD display with new 2-level MENU system and availability in 15W, 25W formats all powered from 12-15V this unit represents realization of dreams for most prospective radio station builders
-
€ 104,99FM Transmitter KitsAudio input board card adds two XLR balanced inputs and two RCA connectors plus USB audio input
Audio input board card adds two XLR balanced inputs and two RCA connectors plus USB audio input. Special designed for the STMAX3015+ FM Transmitter board (stereo+RDS) available in 15W, 25W
-
€ 229,99FM Transmitter KitsFM exciter 100mW Stereo, RDS and LCD display
FM exciter 100mW inclusing Stereo, RDS and LCD display. With DDS digital signal synthesis, excellent audio, on-board stereo, RDS and AES/EBU digital audio.
