: MPX-20USB
: New
: IMG-Stageline Radio Studio Broadcast Mixers Consoles
IMG -Stage Line 3-channel stereo DJ mixer, with USB interface. Plug and mix
By buying this product you can collect up to 7 loyalty points. Your cart will total 7 loyalty points that can be converted into a voucher of € 1,40.
Product information
Product discription:
3-channel stereo DJ mixer, with USB interface. Plug and mix!
- Integrated USB audio interface (will be identified and addressed as an external sound card)
- Full duplex USB port (allows for simultaneous recording and reproduction) for reproduction of digital audio data from a PC as well as for recording mixings onto a PC
- 1 microphone input channel
- 2 stereo input channels, switchable line/phono and USB/line/phono
- 1 stereo output channel (master)
- 1 stereo record output
- Pre-fader listening (CUE) to the stereo input channels via adjustable headphone output
- Crossfader
- LED level display
- Robust metal housing of compact size
- Power supply via USB interface or optional PSU with USB port
Technical specs:
| No. of channels | 4 |
| No. of inputs | 5 |
| Mic input | 1 mV, 1 x 6.3 mm jack |
| Line input | 450 mV, 2 x RCA L/R |
| CD input | - |
| Phono input | 9 mV, 2 x RCA L/R |
| Tape (play) | - |
| Aux input | - |
| Insert input | - |
| effect return | - |
| Master output | 1 V, 1 x RCA L/R |
| Record output | 1 V, 1 x RCA L/R |
| Monitor output | - |
| Booth output | - |
| Aux output | - |
| Insert output | - |
| effect send | - |
| Control room | - |
| Tape (rec) | - |
| Headphones | ≥ 8 Ω, 1 x 3.5 mm jack, 1 x 6.3 mm jack |
| Gooseneck lamp | - |
| USB | yes |
| Frequency range | 20-20,000 Hz |
| THD | 0.1% |
| S/N ratio | 63 dB, unweighted |
| Crosstalk | - |
| Equalizer bass | - |
| Equalizer midrange | - |
| Equalizer treble | - |
| equalizer | - |
| Talkover | - |
| Phantom power | - |
| Crossfader | yes |
| Media player | - |
| Amplifier | - |
| Power supply | DC current 5 V/500 mA via USB interface |
| Mains voltage | - |
| Mains frequency | - |
| Power consumption, operation | - |
| Alternative operating voltage | DC current 5 V |
| Alternative power supply | DC current 500 mA |
| Admiss. ambient temp. | 0-40 °C |
| Dimensions | 150 x 70 x 140 mm |
| Width | 150 mm |
| Height | 70 mm |
| Depth | 140 mm |
| Rack spaces, RS | - |
| Weight | 700 g |
