IMG-Stage Line

MPA-102

1-channel low-noise microphone preamplifier, for mains operation or battery operation.

By buying this product you can collect up to 5 loyalty points. Your cart will total 5 loyalty points that can be converted into a voucher of € 1,00.


€ 114,99

Discount on your Order Discount on your Order
Free Shipping Free Shipping in NL
Volume Discount Volume Discount
Bonus System Bonus System
Secure Payment Secure Payment
Money Back Guarantee Money Back Guarantee
Trustpilot Trustpilot

Volume discounts

Quantity Discount You Save
2 2% Up to € 4,60
4 4% Up to € 18,40
6 6% Up to € 41,40
8 8% Up to € 73,59
10 10% Up to € 114,99

Product information IMG-Stage Line MPA-102 1-channel low-noise microphone preamplifier



1-channel low-noise microphone preamplifier, for mains operation or battery operation.




  • 1 microphone input, XLR, bal.
  • Gain, 11 steps 20-70dB
  • LED green/red for operation/peak
  • Phantom power +24V, can be switched on additionally
  • Microphone phase can be switched
  • Lo cut 100Hz, hi cut 12kHz, 12dB/oct., switchable
  • 1 preamplifier output
  • 1 stereo line input
  • 1 stereo line output
  • Level control and panorama control for mixing the microphone signal to the stereo line channel



MPA-102
Technical Facts Amplifiers
  • Frequency range20-20,000Hz
  • Input sensitivity 0.3-150mV, switchable
  • Input impedance
  • Mic2.2kΩ Stereo line10kΩ
  • Outputs Line, bal.1V/100Ω, 12V max.
  • Stereo line1V/100Ω, 6Vmax.
  • Stereo master-
  • Filter, low cut100Hz/-3dB, 12dB/oct.
  • Filter, high cut12kHz/-3dB, 12dB/oct.
  • Gain, mic20-70dB
  • Gain, stereo line0dB S/N ratio,
  • mic> 66dB (unweighted)
  • S/N ratio, line80dB (unweighted)
  • THD < 0.01%
  • Power supply 15V? via supplied plug-in PSU 10VA; alternatively 4 x 9V battery
  • Dimensions116x55x125mm
