IMG-Stage Line MXR-80 8-channel audio mixer

MXR-80 8-channel audio mixer View larger
Previous Next

€ 229,99

Volume discounting

Number Discount You save
2 2% To € 9,20
4 4% To € 36,80
6 6% To € 82,80
8 8% To € 147,19
10 10% To € 229,99

Brand: IMG-Stage Line

Model: MXR-80

Stands: New

Categories: Monacor Studio Mixers

MXR-80 8-channel audio mixer, with integrated MP3 player and Bluetooth receiver

8 other products in category - Monacor Studio Mixers

Viewed products

Product information

MXR-80 8-channel audio mixer, with integrated MP3 player and Bluetooth receiver

  • Integrated USB audio interface (will be identified and addressed as an external sound card)
  • Full-duplex USB port (allows for simultaneous recording and reproduction) for reproduction of digital audio data from a PC and for recording mixings onto a PC
  • 6 mono input channels with gain control, 3-way equalizer and pan pot
  • 1 stereo input channel with 3-way equalizer and balance control
  • MP3 player
  • USB port
  • Bluetooth receiver
  • DSP delay, adjustable
  • Adjustable aux return input and FX send output
  • Tape record/play connections
  • 5-band stereo graphic equalizer
  • +48 V phantom power, can be activated as required
  • Pre-fader listening (PFL) to the stereo input channels via adjustable headphone output
  • Stereo LED level display

SPECIFICATIONS

Input channels 8
Number of mix/mono 6
No. of stereo 1
Mic input 2.2 mV, bal. 8 x XLR
Line input 50 mV (stereo), 1 x 6.3 mm jack L/R

30 mV (mono), 8 x 6.3 mm jack
Tape (play) 290 mV, 1 x RCA L/R
Aux input 420 mV, 1 x 6.3 mm jack L/R
Master output 880 mV, bal. 1 x XLR L/R

880 mV, 1 x 6.3 mm jack L/R
Effect send 9 V, 1 x 6.3 mm jack
Tape (rec) 400 mV, 1 x RCA L/R
Headphones ≥ 8 Ω, 1 x 6.3 mm jack
USB yes
Bluetooth yes
Frequency range 20-20,000 Hz
THD < 0.03%
S/N ratio > 82 dB(A)
Equalizer bass ±15 dB/80 Hz
Equalizer midrange ±15 dB/2.5 kHz
Equalizer treble ±15 dB/12 kHz
equalizer 5-band equalizer
Phantom power +48 V
Power supply ˜ 230 V/50 Hz/25 VA
Mains voltage ~ 230 V
Mains frequency 50 Hz
Power consumption, operation 25 VA
Admiss. ambient temp. 0-40 °C
Width 382 mm
Height 53 mm
Depth 340 mm
Weight 3.4 kg
Packing dimensions (W x H x L) 0.43 x 0.41 x 0.09 m
Gross weight 3.89 kg
Net weight 3.42 kg
