070AG-25ohm-per foot

    070AG-25

          New

          Specifications for 0.07inch semi-rigid 25ohm cable:
          - Impedance: 25 ohms
          - Diameter: 1.8mm
          - Center conductor diameter: 0.81mm
          - Outer plating: Silver plated copper
          - Dielectric: FEP

          More details

          No reward points for this product.


                € 12,39

                Discount on your Order Discount on your Order
                Free Shipping Free Shipping in NL
                Volume Discount Volume Discount
                Bonus System Bonus System
                Secure Payment Secure Payment
                Money Back Guarantee Money Back Guarantee
                Trustpilot Trustpilot

        Volume discounts

          Quantity Discount You Save
          2 2% Up to € 0,50
          4 4% Up to € 1,98
          6 6% Up to € 4,46
          8 8% Up to € 7,93
          10 10% Up to € 12,39

        More info 070AG-25ohm-per foot

        Specifications for 0.07inch semi-rigid 25ohm cable:
        - Impedance: 25 ohms
        - Diameter: 1.8mm
        - Center conductor diameter: 0.81mm
        - Outer plating: Silver plated copper
        - Dielectric: FEP
        - Center conductor material: SPC
        - Capacitance: 190pF/m
        - Max voltage(60Hz rms): 2500V
        - Min inside bend radius: 3.18mm
        - Weight: 15g/meter
        - Cut off frequency: 58GHz
        - Attenuation 0.5GHz: 21.7dB/100 feet
        - Attenuation 1GHz: 30.9dB/100 feet
        - Attenuation 5GHz: 71.4dB/100 feet
        - Attenuation 20GHz: 151.1dB/100 feet
        - Maximum power 0.5GHz: 78.1W
        - Maximum power 1GHz: 55W
        - Maximum power 5GHz: 24W
        - Maximum power 20GHz: 12W
        - Max power handling @100MHZ: ~150W
