Brand: DMR-Electronics
Model:
Condition: New
Category: Coaxial cables
The CELF200 coaxial cable (4.95mm) is the high-quality, low-loss alternative to the traditional RG58 cable. Because the outer diameter is identical, this cable can often be used one-to-one as an upgrade. Thanks to the solid copper core and double shielding (aluminum foil + braided sheath), you benefit from significantly lower losses, which is immediately noticeable, especially at higher frequencies such as GSM, 3G, 4G and WiFi.
11 other products in category - Coaxial cables
-
Aircell 7 Coax cable
-
ECOFLEX 15 Coax cable
-
CELF 174 HF double shielded Coax cable per 10 m
-
RG 214, 50 Ohm CABLE ( per 10m )
-
RG142 U high temperature teflon coax cable, 10 meter
-
RG58C-U Coax cable 50 ohm, per 10 meter, black
-
Aircom Premium Coax cable
-
Cellflex Coax Cable 1/2 LCF, per 10 meter
-
CELF 400 LOW LOSS COAX CABLE
-
Ecoflex 10 Coax Plus cable
-
Aircell 5 Coax cable
Product information
Minimal attenuation and superior performance: Coaxial cable CELF200
For high-frequency applications where every decibel loss counts, the CELF200 coaxial cable is the perfect choice. While the standard RG58 cable often loses too much signal at higher frequencies, this cable excels due to its excellent attenuation values (only 30.86 dB per 100 meters at 1000MHz). This makes the cable ideally suited for critical connections around GSM, 3G, 4G LTE and WiFi networks, as well as for professional antenna installations.
High-quality construction with double shielding
The secret of the low attenuation lies in the superior construction of the cable. The cable has a solid inner core of 100% pure copper with a thickness of 1.12 mm. This is surrounded by a double shielding layer: an aluminum-coated foil and a sturdy braided sheath of tinned copper with a high density of 88%. This double barrier keeps out unwanted external signals and ensures that the internal signal is optimally preserved.
Ease of installation and compatibility
With an outer diameter of 4.95 mm, the cable is physically as thick as an RG58 cable, making it easy to pull through existing pipes or penetrations. The minimum bending radius of 25 mm also ensures smooth processing in corners and housings.
Pay attention to connectors: Because the solid copper core is slightly thicker than the multi-conductor core of a standard RG58, regular RG58 connectors often do not fit directly. However, our special RG58-compatible connectors are fully compatible and fit seamlessly with this cable.
4. Technical Specifications
| Property | Specification |
| Impedance | 50 ohms |
| Thickness | 4.95 mm |
| Color | Black |
| Inner core thickness | 1.12 mm |
| Inner core material | Full copper |
| Inner core structure | Solid |
| Foil shield | Yes, aluminum coated |
| Sheath material | Tinned copper |
| Mantle structure | 16x6/0.12mm |
| Sheath density | 88 % |
| Outer sheath material | PVC |
| Halogen free sheath | No |
| Minimum bend radius | 25 mm |
| Attenuation per 100m at 1000MHz | 30.86 dB |
| Weight per 100m | 3.7 kg |
