Brand: IMG-Stage Line
Model: MXR-80
Stands: New
Categories: Monacor Studio Mixers
MXR-80 8-channel audio mixer, with integrated MP3 player and Bluetooth receiver
8 other products in category - Monacor Studio Mixers
-
GNL-404 LED gooseneck light
-
6-Channel Stereo Audio Mixer for DJ & PA
-
3-channel stereo DJ mixer, with USB interface. Plug and mix
-
MMX-11USB 2-Channel Miniature Audio Mixer with USB Interface
-
MPX 206 SW 6 channel stereo mixer
-
MXR-6 6-channel audio mixer
-
MXR-120 12-channel audio mixer
-
MXR-4 4-channel audio mixer
Product information
MXR-80 8-channel audio mixer, with integrated MP3 player and Bluetooth receiver
- Integrated USB audio interface (will be identified and addressed as an external sound card)
- Full-duplex USB port (allows for simultaneous recording and reproduction) for reproduction of digital audio data from a PC and for recording mixings onto a PC
- 6 mono input channels with gain control, 3-way equalizer and pan pot
- 1 stereo input channel with 3-way equalizer and balance control
- MP3 player
- USB port
- Bluetooth receiver
- DSP delay, adjustable
- Adjustable aux return input and FX send output
- Tape record/play connections
- 5-band stereo graphic equalizer
- 48 V phantom power, can be activated as required
- Pre-fader listening (PFL) to the stereo input channels via adjustable headphone output
- Stereo LED level display
SPECIFICATIONS
| Input channels | 8 |
| Number of mix/mono | 6 |
| No. of stereo | 1 |
| Mic input | 2.2 mV, bal. 8 x XLR |
| Line input | 50 mV (stereo), 1 x 6.3 mm jack L/R
30 mV (mono), 8 x 6.3 mm jack |
| Tape (play) | 290 mV, 1 x RCA L/R |
| Aux input | 420 mV, 1 x 6.3 mm jack L/R |
| Master output | 880 mV, bal. 1 x XLR L/R
880 mV, 1 x 6.3 mm jack L/R |
| Effect send | 9 V, 1 x 6.3 mm jack |
| Tape (rec) | 400 mV, 1 x RCA L/R |
| Headphones | ≥ 8 Ω, 1 x 6.3 mm jack |
| USB | yes |
| Bluetooth | yes |
| Frequency range | 20-20,000 Hz |
| THD | < 0.03% |
| S/N ratio | > 82 dB(A) |
| Equalizer bass | ±15 dB/80 Hz |
| Equalizer midrange | ±15 dB/2.5 kHz |
| Equalizer treble | ±15 dB/12 kHz |
| equalizer | 5-band equalizer |
| Phantom power | 48 V |
| Power supply | ˜ 230 V/50 Hz/25 VA |
| Mains voltage | ~ 230 V |
| Mains frequency | 50 Hz |
| Power consumption, operation | 25 VA |
| Admiss. ambient temp. | 0-40 °C |
| Width | 382 mm |
| Height | 53 mm |
| Depth | 340 mm |
| Weight | 3.4 kg |
| Packing dimensions (W x H x L) | 0.43 x 0.41 x 0.09 m |
| Gross weight | 3.89 kg |
| Net weight | 3.42 kg |
